Dual Pro Sportsman SS3 Gel Battery Charger


12/24/36 Volt 10 amp 3 bank waterproof marine grade charger.

The Dual Pro Sportsman SS3 marine battery charger is a 3 bank, independent output, 10 amp 12 volt per bank, temperature compensation charger, and is available with a true gel microprocessor. Note: not all sealed batteries are true gel - if in doubt please call. The SE series are heavy duty, waterproof, and fully potted for vibration resistance. They feature powder coated aluminum bases suitable for salt water environments. They can be built as portable chargers, with alligator clips. The independent output battery chargers have a separate positive and negative connector for each bank, and a separate microprocessor for each bank which controls the charging algorithm. They can be used on batteries of differing state of charge, age, size, or type (sealed, flooded). This works well in marine applications with a starting battery and a trolling setup. It also is suitable for series strings of 12 volt batteries for 24 or 36 volts. After each battery has its own positive and negative connection, the microprocessor for each bank does not care if they are in series or parallel. This is useful in 24 volt or 36 volt applications where one of the 12 volt batteries in the string is supplying some 12 volt loads (like communications, radar, etc.), and the batteries end up with an imbalance. A straight output 24 volt or 36 volt charger used in this situation would not properly charge the batteries and fix the imbalance.

The Sportsman SS3 three output 10 amp battery charger is appropriate for 12 to 36 volt applications where wet or harsh environments exist. They have provisions for mounting (permanent installation), and are built for water, vibration, and temperature. They are used in boating applications, like boats with a starting battery and a trolling motor system. In a trolling application, we recommend batteries up to about 100 amp hours capacity with this model. The 110 to 150 amp hour setups should use a 15 amp per bank charger. The SS3 is a well built charger, which can be mounted onboard for years of dependable service. They are built in the USA, which is uncommon for electronic items.

For more information see our Battery Charging Tutorial


   Click image for larger picture, "Back" button to return


Dual Pro SS3 Part#: SS3/Gel

Dual Pro 12/24/36 Volt
Sportsman GEL Charger

$315


FREE GROUND SHIPPING ON THIS MARINE CHARGER!!


Specifications:  Features:
Dim (LxWxH):11.5 x 8.0 x 5.0 Fully Waterproof
Actual Weight:17.0 Overcharge Protection
Ship Weight:20.0 Reverse Polarity Protection
AC Input:115 VAC Temperature Compensation
Output:10/10/10 Amps Ignition Protected
Banks:3 Short Circuit Protected
Approvals:CE LED Readout
Approvals:USCG 33 CFR183.410 True Gel Profile
Warranty:3 Years Made In USA

Cable Extensions:

5 foot cable extension 10 foot cable extension
$23
Dual Pro 5 Foot
Charger Cable Extension
CCx5
$27
Dual Pro 10 Foot
Charger Cable Extension
CCx10


15 foot cable extension
$31
Dual Pro 15 Foot
Charger Cable Extension
CCx15


Any of the following add about 2 days build time, and must be called in:

For portable units, add $10.




Be sure to see our battery charging tutorial.
