Cotek S1500-124 24 Volt Pure Sine Inverter


1500 watt output pure sine wave.

The Cotek S1500-124 24 volt pure sine inverter is a heavy duty commercial unit, engineered for reliable, long term use. The manufacturer emphasizes low failure rate in engineering their products, and doesn't compromise quality in component selection, resulting in a low failure rate (yes, all products have a measured failure rate, particularly electronic items) of less than 100 ppm, and a stated company goal of less than 50 ppm within the year. This Samlex 1500 watt model is a switch mode (microprocessor controlled), highly efficient inverter, providing a continuous 1500 watts of pure sine 115 VAC power with a 2000 watt surge, from a 24 volt battery or battery pack. This unit has a low no-load current draw of 1.5 watts, RS 232 interface, a low battery alarm set at 20.4 volts DC and a low battery shut down set at 19.0 volts DC to protect the battery pack, and meters for battery voltage and watt output. The Samlex S1500-124B2 is suitable for medium AC power demands such as laptop computers, video cameras, DVD players, stereo equipment, marine electronics, industrial applications, etc.

Applications include mobile labs, law enforcement command trailers, surveillance vehicles/trailers, mobile offices, boats, RVs and camping, telecommunications, construction sites, solar systems, and emergency backup situations, or anywhere a 24 volt DC storage source is used. Other frequent uses are mobile carts for medical use or inventory control or accounting, or mobile cash registers for fairs or other on location retail vending, and anything that requires a 24 volt pure sine inverter AC power source for efficient operation. The Cotek S series is available in 12 volt, 24 volt and 48 volt DC input voltages, and are designed for years of trouble free service.

For more information see our Inverter Tutorial


   Click image for larger picture, "Back" button to return


Cotek 1500 Watt Pure Sine Inverter Part#: SA1500-124

Cotek 1500 Watt
24 Volt Input
Pure Sine Inverter

$499




Specifications:  Features:
Dim (LxWxH):15.4 x 10.8 x 4.1 Switch Mode Design
Actual Weight:14.5 High Efficiency
Ship Weight:15.5 Overload Protection
DC Input:20 - 326 VDC Low Battery Alarm
Output Voltage:120 +/- 3% VAC Low Battery Shutdown
Output:1500 Watts Battery volt & output watt meter
Output Surge:2000 Watts Temperature Controlled Fan
Temperature:32 F to 104 F RS232 Interface
Warranty:2 Years UL458, CE, FCC Class B


DC-2000 Inverter Installation Kit - 200 Amp Fuse

DC-2000 Inverter installation kit - 200 amp MRBF-200 Fuse Part#: DC-2000-Kit

Inverter Install Kit
2 Gauge 200 Amp Fuse

$148

2 Gauge Cable Kit with 200 Amp Fuse

  • 10 feet of #2 AWG red marked cable
  • 10 feet of #2 AWG black marked cable
  • Cooper Bussman Marine Rated Battery Fuse Holder
  • 200 amp MRBF fuse
  • Anti-corrosion connectors
  • Cable operating temperature -40C to 90C
  • Cable - high strand count annealed and tinned copper

Be sure to see our inverter tutorial.
